顺络电感全系列产品
更新时间：2021-04-02
本公司经销顺络全系列电感多年，多数型号都有库存现货，没有现货的可以快速在原厂订货，有需要请与客服联系。
顺络电感产品目录
1、射频电路用电感
2、一般信号线用电感
3、电源线用电感
1、射频电路用电感
2、一般信号线用电感
3、电源线用电感
射频电路用电感目录
| 产品照片 | 类别 | 电感 | 额定电流 | 尺寸代码 | 系列 | 规格书 |
|---|---|---|---|---|---|---|
 |
Multilayer/High Q | 0.6 to 100nH | 60 to 600mA | 0603/0201 inch | SDCL0603Q-02 |
SDCL0603Q -02 PDF |
|
|
Multilayer/STD | 1.0 to 360nH | 50 to 400mA | 1005/0402 inch | SDCL1005C | SDCL-D PDF |
| 1.0 to 470nH | 150 to 500mA | 1608/0603 inch | SDCL1608C | |||
 |
Multilayer/High Q | 1.0 to 15nH | 430 to 1000mA | 1005/0402 inch | HQ1005 | HQ PDF |
 |
Multilayer/High SRF | 1.0 to 100nH | 100 to 500mA | 1005/0402 inch | SDHL1005 | SDHL PDF |
| 10 to 180nH | 150 to 500mA | 1608/0603 inch | SDHL1608 | |||
 |
Wire Wound/STD | 0.8 to 120nH | 110 to 1000mA | 1005/0402 inch | SDWL1005C | SDWL-C PDF |
| 1.6 to 560nH | 70 to >1150mA | 1608/0603 inch | SDWL1608C | |||
| 2.2 to 1000nH | 150 to >600mA | 2012/0805 inch | SDWL2012C | |||
| 4.7 to 8200nH | 150 to 1000mA | 2520/1008 inch | SDWL2520C | |||
| 3.3 to 1200nH | 300 to1000mA | 3216/1206 inch | SDWL3216C | |||
| 3.9 to 8600nH | 200 to 1000mA | 3225/1210 inch | SDWL3225C | |||
| 1000 to 33000nH | 145 to 480mA | 4532/1812 inch | SDWL4532C | |||
|
|
Wire Wound | 1.5 to 100nH | 120 to 1000mA | 1005/0402 inch | SDWL1005C-M |
SDWL-C-M |
| 2.2 to 470nH | 75 to 1400mA | 1608/0603 inch | SDWL1608C-M | |||
|
|
Wire Wound | 1.3 to 75nH | 320 to 3150mA | 1005/0402 inch |
SDWL1005C-M8X |
SDWL-C-M8X PDF |
|
|
Lower DCR and Hight Q | 1.0 to 51nH | 360 to 2300mA | 1005/0402 inch |
SDWL1005-CP |
SDWL-CP PDF |
| 1.8 to 390nH | 170 to 2100mA | 1608/0603 inch |
SDWL1608-CP |
一般信号线用电感目录
| 产品照片 | 类别 | 电感 | 额定电流 | 尺寸代码 | 系列 | 规格书 |
|---|---|---|---|---|---|---|
 |
Multilayer/STD | 0.047 to 3.3μH | 10 to 25mA | 1005/0402 inch | SDFL1005 | SDFL PDF |
| 0.047 to 33μH | 1 to 50mA | 1608/0603 inch | SDFL1608 | |||
| 0.047 to 47μH | 4 to 300mA | 2012/0805 inch | SDFL2012 | |||
| 0.047 to 47μH | 5 to 300mA | 3216/1206 inch | SDFL3216 | |||
 |
Wire Wound | 0.018 to 0.2μH | 390 to 1400mA | 1005/0402 inch | WL1005FS | WL-FS PDF |
| 0.047to 22μH | 70 to 2600mA | 1608 0603 inch | WL1608FS | |||
 |
Wire Wound/STD | 0.27 to 68μH | 40 to 350mA | 2012/0805 inch | SDWL2012FW | SDWL-FW PDF |
| 0.33 to 10μH | 300 to 700mA | 2520/1008 inch | SDWL2520FW | |||
| 1.5 to 18μH | 130 to 320mA | 3216/1206 inch | SDWL3216FW | |||
| 0.12 to12μH | 140 to 450mA | 3225/1210 inch | SDWL3225FW |
电源线用电感目录
| 产品照片 | 类别 | 电感 | 额定电流 | 尺寸代码 | 系列 | 规格书 |
|---|---|---|---|---|---|---|
|
|
Multilayer/STD, For Choke | 0.1 to 10μH | 50 to 700mA | 1608/0603 inch | MCL1608 | MCL PDF |
| 0.1 to 10μH | 60 to 1000mA | 2012/0805 inch | MCL2012 | |||
|
|
Multilayer/STD | 0.22 to 2.2μH | 250 to 1700mA | 1608/0603 inch | MPH1608 | MPH PDF |
| 0.47 to 10μH | 130 to 1300mA | 2012/0805 inch | MPH2012 | |||
| 0.47 to 10μH | 200 to 1600mA | 2016/0806 inch | MPH2016 | |||
| 0.47 to 10μH | 250 to 1500mA | 2520/1008 inch | MPH2520 | |||
|
|
Multilayer/STD | 2.2 to 4.7μH | 180 to 300mA | 2012/0805 inch | MCL2012A | MCL-A PDF |
| 1.0 to 2.2μH | 550 to 900mA | 2016/0806 inch | MCL2016A | |||
| 1.5 to 4.7μH | 250 to 600mA | 2520/1008 inch | MCL2520A | |||
 |
Magnetic Shielded(Large Isat) | 0.24 to 10μH | 0.95 to 5.5A | 2.0×1.6×1.0 | WPN201610 | WPN PDF |
| 0.33 to 10μH | 1 to 5.5A | 2.5×2.0×1.0 | WPN252010 | |||
| 1.0 to 4.7μH | 3 to 4.2A | 2.5×2.0×1.2 | WPN252012 | |||
| 1.0 to 4.7μH | 1.5 to 5.4A | 3.0×3.0×1.2 | WPN3012 | |||
| 0.33 to 22μH | 1.35 to 9.7A | 4.0×4.0×1.2 | WPN4012 | |||
| 1.0 to 3.3μH | 5.5 to 3.5A | 4.0×4.0×2.0 | WPN4020 | |||
 |
Magnetic Shielded(Large Isat) | 0.47 to 22μH | 1.7 to 11A | 6.5×6.5×3.0 | WPL6530 | WPL PDF |
 |
Wire Wound/Shielded Type with Magnetic Glue, Low DCR |
0.16 to 10μH | 0.5 to 4.3A | 2.0×1.6×1.0 | SPH201610H | SPH PDF |
| 0.05 to 2.2μH | 0.75 to 4.8A | 2.0×1.6×1.0 | SPH201610U | |||
| 0.16 to 33μH | 0.35 to 5.2A | 2.0×2.0×1.0 | SPH202012H | |||
| 0.16 to 33μH | 0.25 to 3.6A | 2.5×2.0×1.0 | SPH252010H | |||
| 0.16 to 47μH | 0.25 to 6.5A | 2.5×2.0×1.2 | SPH252012H | |||
| 1 to 22μH | 0.5 to 2.2A | 3.0×3.0×1.2 | SPH3012 | |||
| 0.47 to 4.7μH | 0.35 to 2.4A | 3.0×3.0×1.5 | SPH3015 | |||
| 0.47 to 100μH | 0.25 to 3A | 4.0×4.0×1.2 | SPH4012 | |||
| 1.0 to 330μH | 0.26 to 4.0A | 4.0×4.0×1.8 | SPH4018 | |||
| 0.33μH | 7.5A | 4.0×4.0×2.0 | SPH4020 | |||
| 0.33 to 0.47μH | 8.2 to 17A | 4.0×4.0×3.0 | SPH4030 | |||
| 1.0 to 47μH | 1.1 to 7.8A | 8.0×8.0×3.0 | SPH8030H | |||
 |
Wire Wound/STD, Shielded Type with Magnetic Glue |
0.47 to 10μH | 0.78 to 3.35A | 2.5×2.0×1.0 | SWPA252010S | SWPA PDF |
| 0.47 to 22μH | 0.59 to 4.27A | 2.5×2.0×1.2 | SWPA252012S | |||
| 1.0 to 56μH | 0.21 to 1.40A | 3.0×3.0×1.0 | SWPA3010S | |||
| 0.82 to 100μH | 0.21 to 2.05A | 3.0×3.0×1.2 | SWPA3012S | |||
| 1.0 to 68μH | 0.28 to 2.32A | 3.0×3.0×1.5 | SWPA3015S | |||
| 1.0 to 22μH | 0.45 to 2.0A | 4.0×4.0×1.0 | SWPA4010S | |||
| 1.0 to 220μH | 0.27 to 4.80A | 4.0×4.0×1.8 | SWPA4018S | |||
| 0.33to 100μH | 0.48 to 7.5A | 4.0×4.0×2.0 | SWPA4020S | |||
| 1.2 to 47μH | 0.40 to 3.10A | 4.0×4.0×2.6 | SWPA4026S | |||
| 0.68 to 120μH | 0.55 to 6.8A | 4.0×4.0×3.0 | SWPA4030S | |||
| 1.0 to 15μH | 1.25 to 4.40A | 5.0×5.0×1.2 | SWPA5012S | |||
| 0.47 to100μH | 0.53 to 6.15A | 5.0×5.0×2.0 | SWPA5020S | |||
| 1.0 to 150μH | 0.65 to 7.35A | 5.0×5.0×4.0 | SWPA5040S | |||
| 0.50 to 33μH | 0.95 to 4.50A | 6.0×6.0×2.0 | SWPA6020S | |||
| 1.0 to 100μH | 0.65 to 5.75A | 6.0×6.0×2.8 | SWPA6028S | |||
| 0.47 to 330μH | 0.57 to 15A | 6.0×6.0×4.5 | SWPA6045S | |||
| 0.82 to 330μH | 0.68 to 13.8A | 8.0×8.0×4.0 | SWPA8040S | |||
 |
Wire Wound/STD, Magnetic Shielded | 1.0 to 330μH | 0.50 to7.00A | 12.5×12.5×5.0 | SWRB1204S | SWRB-S PDF |
| 1.0 to 680μH | 0.48 to 8.00A | 12.5×12.5×6.0 | SWRB1205S | |||
| 1.0 to 1000μH | 0.55 to 10.00A | 12.5×12.5×8.0 | SWRB1207S | |||
 |
Wire Wound/STD, Magnetic Shielded | 3.3 to 82μH | 0.38 to 1.94A | 7.0×6.8×3.0 | SWRH0602B | SWRH-B PDF |
| 10 to120μH | 0.39 to 1.35A | 7.0×6.8×5.0 | SWRH0604B | |||
| 2.2 to180μH | 0.39 to3A | 7.8×7.8×4.0 | SWRH0703B | |||
| 10 to 270μH | 0.34 to 1.84A | 7.8×7.8×5.0 | SWRB0704B | |||
| 2.2 to 390μH | 0.39 to 4 A | 10.5×10.5×5.0 | SWRH1004B | |||
| 1.0 to 330μH | 0.50 to 7.00A | 12.5×12.5×5.0 | SWRH1204B | |||
| 1.0 to 680μH | 0.48 to 8.00A | 12.5×12.5×6.0 | SWRH1205B | |||
| 1.0 to 1000μH | 0.55 to 10.00A | 12.5×12.5×8.0 | SWRH1207B | |||
 |
Wire Wound/STD, Magnetic Shielded | 1.0 to 120μH | 0.65 to 6.50A | 10.6×10.5×3.0 | SWRH1003C | SWRH-C PDF |
| 1.5 to 330μH | 0.52 to 6.50A | 10.6×10.5×4.0 | SWRH1004C | |||
| 3.3 to 820μH | 0.48 to 6 A | 10.6×10.5×5.2 | SWRH1005C | |||
 |
Wire Wound/STD, Magnetic Shielded | 2.5 to 100μH | 0.75 to 4.50A | 10.1×8.3×3.0 | SWRH8D28C | SWRH-DC PDF |
| 1.5 to 100μH | 0.88 to 6.00A | 10.1×8.3×4.0 | SWRH8D38C | |||
| 2.0 to 100μH | 0.80 to 5.50A | 10.1×8.3×4.5 | SWRH8D43C | |||
 |
Wire Wound/STD, Magnetic Shielded | 1.2 to 10μH | 0.35 to 0.90A | 3.3×3.3×1.3 | SWRH2D11R | SWRH-DR PDF |
| 1.5 to 12μH | 0.62 to 1.80A | 3.3×3.3×1.6 | SWRH2D14R | |||
| 2.2 to 33μH | 0.24 to 0.85A | 3.3×3.3×2.1 | SWRH2D18R | |||
| 2.7 to 18μH | 0.21 to 0.50A | 4.2×4.2×1.3 | SWRH3D11R | |||
| 1.5 to 22μH | 0.52 to1.85A | 4.2×4.2×1.6 | SWRH3D14R | |||
| 1.5 to 33μH | 0.32 to 1.55A | 4.2×4.2×1.8 | SWRH3D16R | |||
 |
Wire Wound/STD, Magnetic Shielded | 1.5 to 33μH | 0.32 to 1.35A | 4.2×4.2×1.8 | SWRH3D16S | SWRH-DS PDF |
| 3.3 to 47μH | 0.35 to 1.45A | 4.2×4.2×2.1 | SWRH3D18S | |||
| 3.3 to 47μH | 0.48 to 2.00A | 4.2×4.2×3.2 | SWRH3D28S | |||
| 1.0 to 68μH | 0.24 to 1.72A | 5.0×5.0×2.0 | SWRH4D18S | |||
| 1.2 to 150μH | 0.24 to 2.56A | 5.0×5.0×3.0 | SWRH4D28S | |||
| 3.3 to 150μH | 0.31 to 2.00A | 6.0×6.0×2.0 | SWRH5D18S | |||
| 2.2 to330μH | 0.25 to 2.60A | 6.0×6.0×3.0 | SWRH5D28S | |||
| 3.3 to 390μH | 0.23 to 2.80A | 7.0×7.0×3.0 | SWRH6D28S | |||
| 1.5 to 1000μH | 0.20 to 5.20A | 7.0×7.0×4.0 | SWRH6D38S |
